ELECTROLESS NICKEL
ELECTROLESS NICKEL PLATING IS THE CHOICE FOR COATING CORROSION PRONE MATERIALS
Electroless Nickel plating creates a thin, uniform coating that offers superior protection against oxidation, along with moderate abrasion resistance properties.
ELECTROLESS NICKEL PLATING BENEFITS
The list of electroless nickel plating advantages encompasses a wide range of applications.
Application possible up to .003” thickness.- Outstanding protection against oxidation.
- Moderate abrasion-resistance properties.
- Coverage in the deepest details.
LOW-FRICTION COATINGS
Do you have parts prone to getting rubbed the wrong way? Solve your abrasion and wear problems with our abrasion-resistant coatings.
ABRASION-RESISTANT COATINGS
Are release issues causing downtime in your shop? Reduce friction and achieve uniform treatment with our lubricity and release/low-friction coatings.
ELECTROLESS NICKEL PLATING FAQS
Explore how Electroless Nickel compares to standard nickel plating. You’ll learn what makes it ideal for metal components, its benefits for various industries, and how it’s able to resist corrosion so effectively.
How does Electroless Nickel plating compare to standard nickel plating?
Electroless Nickel plating stands out for its ability to coat parts evenly without the need for an electrical current, whereas standard nickel plating relies on electrical conductivity. It creates a thin, uniform layer that enhances corrosion resistance and durability for shapes from simple to complex.
Why choose Electroless Nickel plating for metal components?
Electroless Nickel is ideal for metal components because of its superior corrosion and wear resistance. Thanks to a uniform coating, it reduces friction and withstands the elements of harsh applications, including aerospace and automotive.
Can Electroless Nickel plating prevent rust effectively?
Electroless Nickel significantly reduces the risk of rust because of its exceptional corrosion resistance, especially in saline and alkaline conditions. While no coating is completely infallible, Electroless Nickel is among the most effective options for protecting metal components against corrosion.
45
ROCKWELL HARDNESS
10.5-12.0%
Phosphorus (wt)
1400°F
MAX OPERATING TEMPERATURE
1.0 mil deposit, 1,000+ hours
Corrosion Properties
cal/cm/sec/C 0.0105
Thermal Conductivity
corrosion resistance rating
RELEASE RATING
ABRASION resistance rating
CASE STUDY: Electroless Nickel Protects Aluminum Molds
Food manufacturers often use aluminum for components because it’s soft, lightweight, and easily shaped. But these same properties put aluminum parts at risk for damage. The Bales team was eager to help AM better protect its molds. Our recommendation? Electroless Nickel, an FDA-approved coating.
“Bales helped me meet demanding deadlines with a quick turnaround and went above and beyond to keep our products safe.”
Joseph Sadzewicz, Parts Manager at AM Manufacturing Company
